Project Overview
Wadjay CSL-1200 automatic metal slitter machine slits 1000-1200mm wide, 0.3-0.8mm thick coils at 1500-2000 mm/min. 2-20 strips, 5 ton coil, Cr12MoV blades, CE/ISO.
Automatic Metal Slitter Machine CSL-1200 — Compact Steel Coil Slitting Line Cutter for Light Gauge Metal
Why Choose the CSL-1200 Automatic Metal Slitter Machine?
An automatic metal slitter machine is the productivity multiplier for metal service centers, light-gauge steel fabricators, HVAC ductwork manufacturers, and roofing panel producers that need to convert wide steel coils into precise narrow strips — quickly, cleanly, and with minimal material waste.
The Wadjay CSL-1200 steel coil slitting line cutter is purpose-built for exactly that. It processes cold-rolled steel, galvanized iron (GI), pre-painted steel (PPGI), stainless steel, aluminum, and copper coils in the 1000–1200mm width range and 0.3–0.8mm thickness range at speeds of 1500–2000 mm/min . With a 2–20 strip configurable capacity, 5-ton coil capacity, and a starting price of just $1,000 , the CSL-1200 delivers industrial-grade auto slitting performance in a compact, affordable package.
Key Technical Specifications
| Parameter | CSL-1200 Specification |
|---|---|
| Model | CSL-1200 Automatic Metal Slitter Machine |
| Processing Width Range | 1000 – 1200 mm |
| Material Thickness | 0.3 – 0.8 mm (Light Gauge Metal) |
| Line Speed | 1500 – 2000 mm/min |
| Number of Slitting Strips | 2 – 20 strips (customizable) |
| Max. Coil Weight | 5 Tons (5,000 kg) |
| Blade Material | Cr12MoV / High-Carbon Alloy Tool Steel |
| Machine Weight | 1,200 kg (1.2 Tons) |
| Machine Dimensions (L×W×H) | 180 × 140 × 130 cm |
| Operation Voltage | 380V, 3-Phase, 50Hz/60Hz (customizable) |
| Slitting Arbor | Dual-shaft gang slitter with hardened rotary blades |
| Strip Width Adjustment | Multi-blade spacer system with adjustable locking collars & rubber spacer rings |
| Feed System | Dynamic sheet & coil guide assembly with heavy-duty side-guided entry rails |
| Drive System | Continuous high-torque motor drive with gearbox |
| Traction Rollers | Rubberized anti-scratch drive rollers |
| Safety Features | Fully integrated emergency stop circuitry & protective blade housing |
| Certification | CE / ISO |
Core Engineering Features
The Wadjay automatic metal slitter machine integrates six engineering advantages that set it apart in the compact slitting segment:
- Dynamic Sheet & Coil Guide Assembly — heavy-duty adjustable side-guided entry rails ensure straight material feed, eliminating coil wander and material waste
- High-Carbon Tool Steel Slitting Arbor — dual-shaft gang slitter fitted with hardened rotary blades that execute precise parallel longitudinal cuts without burrs or edge deformation
- Multi-Blade Spacer System — adjustable locking collars and rubber spacer rings allow operators to reconfigure strip width settings rapidly for custom orders
- Continuous High-Torque Motor Drive — heavy-duty motor and gearbox assembly maintain steady feed speeds up to 1500–2000 mm/min across varying metal gauges
- Smooth Anti-Scratch Drive — rubberized traction rollers preserve pre-painted steel or delicate copper/aluminum finishes
- Operator Protection Enclosure — fully integrated emergency stop circuitry and protective blade housing guarantee strict industrial workshop safety compliance
Machine Options:
- Extra pairs of high-carbon alloy slitting blades & rubber spacers
- Upgrade to powered decoiler / pay-off stand
- Custom electrical voltage transformers for localized factory grids (220V/415V/440V at 50Hz/60Hz)
Application Scenarios
The CSL-1200 automatic metal slitter machine serves a wide spectrum of light-gauge metal processing industries :
- 🌬️ HVAC Ductwork Fabrication — continuous slitting of galvanized steel sheets into custom strip widths required for spiral pipes, flange connectors, and duct seams
- 🏠 Roofing & Cladding — accurate flashing strips, metal gutters, and fascia trims directly on site or in local fabrication yards
- ⚡ Electrical & Transformer Production — smooth arbor drive cuts high-conductivity copper foils and thin silicon steel sheets without surface scratches
- 🏢 Light-Gauge Steel Coil Service Centers — multi-width slitting for inventory diversification and just-in-time delivery
- 🏭 Metal Fabrication Workshops — daily high-volume production with micro-adjustable blade clearance controls and low power consumption
The machine’s ability to process cold-rolled steel, galvanized iron, PPGI, stainless steel, aluminum, and copper in a single compact line makes it exceptionally versatile — one machine serves mixed-material workshops without retooling .
Why Wadjay’s CSL-1200 Stands Out
- True compact automatic slitting — 1000–1200mm width, 0.3–0.8mm thickness, 1500–2000 mm/min in a 1,200kg footprint
- Multi-cut gang slitting arbors — hardened high-carbon tool steel blades execute up to 20 parallel cuts simultaneously without burrs or material warping
- Rapid strip width reconfiguration — multi-blade spacer system with adjustable locking collars and rubber spacer rings; change settings in minutes
- Precision entry alignment — heavy-duty side guides prevent sheet drifting during continuous high-speed cutting
- Anti-scratch surface protection — rubberized traction rollers preserve pre-painted steel or delicate copper/aluminum finishes
- Low maintenance drive — high-torque motor drive with CE compliance cuts factory equipment maintenance downtime by half
- 5-ton coil capacity — handles substantial master coils for continuous production runs
- Global voltage ready — 380V 3-phase standard, customizable to 220V/415V/440V at 50Hz/60Hz
- CE/ISO certified — compliant with international export standards
- Factory-direct pricing — starting from just $1,000 USD, no distributor markup
Frequently Asked Questions
Q1: What materials can the CSL-1200 automatic metal slitter process?
A: The machine handles cold-rolled steel, galvanized iron (GI), pre-painted steel (PPGI), stainless steel, aluminum, and copper coils in the 0.3–0.8mm thickness range . It’s optimized for light-gauge metal processing.
Q2: How wide is the processing range and how many strips can be produced?
A: The CSL-1200 processes 1000–1200mm width coils and can be configured for 2–20 parallel strips simultaneously, depending on material thickness and strip width requirements .
Q3: How fast is the slitting speed?
A: Line speed is 1500–2000 mm/min, maintained by a continuous high-torque motor drive with gearbox across varying metal gauges .
Q4: How clean are the cut edges?
A: The dual-shaft gang slitter fitted with Cr12MoV / high-carbon alloy tool steel rotary blades delivers precise parallel longitudinal cuts without burrs or edge deformation . Rubberized traction rollers further protect pre-painted and delicate metal surfaces from scratching.
Q5: How much coil weight can the machine handle?
A: The CSL-1200 handles master coils up to 5 tons (5,000 kg) for continuous production runs .
Q6: How long does a strip width changeover take?
A: The multi-blade spacer system with adjustable locking collars and rubber spacer rings allows operators to reconfigure strip width settings rapidly — change settings in minutes, not hours .
Q7: Can the voltage be customized for my country?
A: Yes. Standard operation voltage is 380V, 3-phase, 50Hz/60Hz, customizable to 220V/415V/440V at 50Hz/60Hz via custom electrical voltage transformers .
Q8: What is the machine footprint and weight?
A: The CSL-1200 has a net machine weight of 1,200 kg (1.2 tons) with overall dimensions of 180 × 140 × 130 cm — compact enough for any workshop while maintaining industrial-grade rigidity .
Q9: What safety features are included?
A: The machine features a fully integrated emergency stop circuitry and protective blade housing that guarantee strict industrial workshop safety compliance .
Q10: What is the starting price?
A: The CSL-1200 automatic metal slitter machine starts at just $1,000 USD — factory-direct pricing with no distributor markup . Contact our sales team for a customized quote based on your specific configuration.
