GB4230 Heavy-Duty Horizontal Band Sawing Machine
Model: GB4230
Quick Specifications
| Working Area: | 1800×900×1600mm |
| Spindle Speed: | 1 - 8000 r.p.m |
| Accuracy: | 0.1 |
| Tool Capacity: | 2 |
Product Video
Description
The GB4230 is a heavy-duty horizontal band sawing machine, engineered for the high-efficiency and precise cutting of various metal materials, including steel, aluminum, copper, and alloys. Built with an ultra-rigid double-column structure for stable operation and minimal vibration, it delivers clean, burr-free cuts for both solid bars and hollow workpieces.
Core Technical Highlights:
Hydraulic Feeding System: Equipped with an advanced hydraulic feeding system and adjustable cutting speed, it ensures smooth, safe, and accurate cutting performance.
Heavy Industrial Build: Ideal for metalworking workshops, steel metal centers, factories, and machinery repair shops.
Global Export Ready: Supports standard 3-phase 380V 50Hz power with customizable voltage configurations for international shipping. ISO 9001 certification and a 12-month warranty.
Technical Specifications
| Parameter | Unit | GB4230 Standard Value |
|---|---|---|
| Max. Cutting Capacity (Round) | mm | 300 |
| Max. Cutting Capacity (Rectangle) | mm | 300×300 |
| Band Saw Speed | m/min | 27-69 |
| Band Wheel Diameter | mm | 400 |
| Band Size (L×W×T) | mm | 4350×34×1.1 |
| Main Motor Power | kW | 4 |
| Hydraulic Pump Power | kW | 0.75 |
| Standard Power Supply | – | 3 Phase 380V, 50Hz |
| Customizable Voltage | – | 3 Phase 220V/415V/440V, 50/60Hz |
| Overall Dimensions (L×W×H) | mm | 1800×900×1600 |
| Net Weight | kg | 1600 |
Features
Double-Column Rigid Structure
High-strength cast iron frame with stress relief treatment ensures stable cutting and long-term dimensional accuracy.
Hydraulic Feeding System
Smooth and precise hydraulic feed control for consistent cutting depth and reduced material waste.
High-Efficiency Metal Cutting
Powerful main motor and adjustable speed deliver fast, clean cuts on steel, aluminum, copper, and other metals.
User-Friendly Operation
Intuitive control panel with emergency stop, easy blade replacement, and centralized lubrication system.
Global Power Compatibility
Standard 380V 50Hz configuration, fully customizable voltage to meet European, American, and Asian grid standards.
Low Maintenance & Safe
Fully enclosed saw blade guard, automatic lubrication, and overload protection for safe and reliable operation.
