M618 Manual Surface Grinder
Model: M618
Quick Specifications
| Working Area: | 1500 × 1200 × 2000mm |
| Spindle Speed: | 2800r/min |
| Accuracy: | ±0.005 |
| Tool Capacity: | 12 |
Product Video
Description
Technical Specifications
| Parameter | Unit | M618 Standard Value |
|---|---|---|
| Table Size | mm | 460 × 180 |
| Max. Grinding Length | mm | 460 |
| Max. Grinding Width | mm | 180 |
| Max. Workpiece Height | mm | 300 |
| Spindle Speed | r/min | 2800 |
| Grinding Wheel Size | mm | 180 × 19 × 31.75 |
| Spindle Motor Power | kW | 1.5 |
| Grinding Accuracy | mm | ±0.005 |
| Net Weight | kg | 850 (Industry standard for M618 manual surface grinder) |
| Standard Power Supply | – | 3 Phase 380V, 50Hz |
| Customizable Voltage | – | 1 Phase 220V / 3 Phase 220V/415V, 50/60Hz |
| Overall Dimensions (L×W×H) | mm | 1500 × 1200 × 2000 |
Features
✅ Heavy-Duty Rigid Construction
Reinforced cast iron bed and column, fully stress-relieved, eliminate chatter during grinding, guaranteeing long-term machining accuracy and stability.
✅ High-Precision Manual Operation
Precision-ground guideways and handwheel feed system enable ultra-fine adjustment, ensuring mirror-like surface finishes and tight dimensional tolerances.
✅ Compact & Versatile Design
Small footprint makes it ideal for small workshops and tool rooms, suitable for grinding steel, aluminum, carbide, and other materials.
✅ Integrated Cooling System
Built-in coolant tank and pump reduce tool wear and workpiece heat, extending grinding wheel life and preventing material deformation.
✅ User-Friendly Operation
Ergonomic handwheel controls and clear status indicators make the machine easy to operate, with minimal training required for operators.
✅ Global Export Compatibility
Multiple voltage options available, compact structure for easy transportation, with comprehensive after-sales support for global customers.
