Mechanical Gear Shaping Machine
Model: Y54
Quick Specifications
| Working Area: | 1100 × 900 × 2000mm |
| Spindle Speed: | 83 / 120 / 169 / 225 (4-Speed)strokes/min |
| Accuracy: | GB/T 7 |
| Tool Capacity: | 12 |
Product Video
Description
Technical Specifications
| Parameter | Unit | Y54 Standard Specification |
|---|---|---|
| Max. External Gear Diameter | mm | 240 |
| Max. Internal Gear Diameter | mm | 260 |
| Max. Machining Module | mm | 6 |
| Max. Ram Stroke Length | mm | 125 |
| Ram Stroke Speed | strokes/min | 83 / 120 / 169 / 225 (4-Speed) |
| Main Motor Power | kW | 2.2 |
| Control System | – | Mechanical |
| Accuracy Grade | – | GB/T 7 |
| Net Machine Weight | kg | 1700 |
| Power Supply | – | 3 Phase 380V, 50Hz (Customizable) |
| Overall Dimensions (L×W×H) | mm | 1100 × 900 × 2000 |
Features
✅ Versatile Gear Machining
Excels at cutting both external spur gears and hard-to-machine internal gears, as well as splines and other non-standard profiles.
✅ Proven Mechanical Reliability
The classic mechanical design features minimal electronics, ensuring low failure rates and easy maintenance for decades of service.
✅ Precision Indexing & Consistency
The automatic indexing mechanism guarantees high-precision tooth spacing, delivering repeatable results critical for gear quality.
✅ Simple & Cost-Effective Operation
Intuitive controls and a straightforward operating principle make it easy to set up and run, reducing operator training time and costs.
✅ Low Total Cost of Ownership
Durable construction and readily available standard parts keep maintenance costs low, making it a highly cost-effective long-term investment.
✅ Global Export Ready
CE-certified with customizable voltage configurations, ready for international shipping and integration into production lines worldwide.
