Multifunctional CNC Automatic Flat Bar Strip Bending Punching Machine
Model: WADJAY-PSC100
Product Video
Description
The Multifunctional CNC Automatic Flat Bar Strip Bending Punching Machine is an advanced mechanical processing solution engineered for the high-speed, continuous manufacturing of structured steel plates, flat bars, and metal strips. Integrating automated decoiling, high-precision roller leveling, hydraulic hole piercing, and multi-angle bending into one seamless line, this industrial machinery transforms raw steel or stainless steel coils into finished brackets, connectors, and mounting hardware. Powered by a smart CNC control platform, it completely replaces manual press and bending operations, maximizing workshop safety, reducing material scrap, and guaranteeing perfect dimensional alignment for automotive, hardware, and structural steel processing industries.
Premium Production Line Components & Workflow:
Heavy-Duty Decoiling System: Non-powered or manual expanding pay-off reels handling coil capacities up to 2 Tons smoothly.
7-Roller Straightening Unit: Driven by a 3.0 kW motor to completely eliminate coil curvature, ensuring perfectly flat strip stocks.
Multi-Station Hydraulic Punching: Dynamic mechanical piercing modules to execute precision mounting hole punching cleanly prior to bending.
Intelligent 4-Point Independent Forming: 8 heavy-duty gear-driven forming stations to progressively shape intricate profile joint joints.
High-Speed Cut-off Synchronization: Tracks material feed to execute burr-free cuts at speeds up to 16 meters per minute (m/min).
Technical Specifications
| Technical Parameters | Specification Values |
| Processing Material | Mild Steel, Stainless Steel, Galvanized Iron |
| Applicable Strip Width Range | 30 mm – 100 mm |
| Max. Strip Thickness Allowed | ≤ 2.0 mm (Straightening) / ≤ 3.5 mm (Decoiling) |
| Feeding & Processing Speed | Max. 16 meters / minute (m/min) |
| Straightening Motor Power | 3.0 kW |
| Leveling Roller Configuration | 7 Rollers Layout |
| Machine Drive & Station Setup | Gear Driven / 8 Active Forming Stations |
| Inner / Outer Diameter of Coil | ф480-520 mm / φ1300 mm |
| Maximum Coil Load Capacity | ≤ 2,000 kg (2 Tons) |
| Total Net Equipment Weight | 2,500 kg (2.5 Tons) |
Features
Continuous Stamping & Bending Line: Executes decoiling, leveling, punching, bending, and cutting in a single continuous automated cycle to slash factory labor costs.
4-Point Independent Adjustment: Specialized roller layout provides micro-level tension control to eliminate metal twisting or surface scratching during high-speed feeding.
Heavy-Duty Gearbox Drive: Incorporates premium motor, pump, and engine core elements compliant with CE standards, guaranteeing stable 24/7 continuous shift runs.
