PB65-25-2W Dual-Spindle CNC Profile Machining Center
Model: PB65-25-2W
Quick Specifications
| Working Area: | 4200 × 2500 × 2300mm |
| Spindle Speed: | 12000 / 15000 (Optional, per spindle)rpm |
| Accuracy: | ±0.03 / 1000mm |
| Tool Capacity: | 24 |
Product Video
Description
Technical Specifications
| Parameter | Unit | PB65-25-2W Standard Specification |
|---|---|---|
| X Axis Travel | mm | 2500 |
| Y Axis Travel | mm | 650 × 2 (Dual Workstations) |
| Z Axis Travel | mm | 400 × 2 (Dual Spindles) |
| Spindle Speed Range | rpm | 12000 / 15000 (Optional, per spindle) |
| Spindle Power (S1/S6) | kW | 7.5 / 11 × 2 (Dual Spindles) |
| Rapid Traverse Speed (X/Y/Z) | m/min | 60 / 30 / 30 (per axis) |
| Max. Cutting Feed Speed | mm/min | 15000 |
| Tool Magazine Capacity | pcs | 12 / 24 × 2 (Optional, per spindle) |
| Control System | – | Siemens / Fanuc (Dual Panels) |
| Positioning Accuracy | mm | ±0.03 / 1000 |
| Repeatability | mm | ±0.015 |
| Net Machine Weight | kg | 7500 |
| Power Supply | – | 3 Phase 380V, 50Hz (Customizable) |
| Overall Machine Dimensions (L×W×H) | mm | 4200 × 2500 × 2300 |
Features
✅ Double Productivity with Dual Spindles
Two independent spindles enable simultaneous machining of two profiles, cutting cycle time by half and doubling production output.
✅ Dual Workstation Compatibility
2500mm X-axis travel and dual Y-axis stations accommodate two 2.5m profiles, ideal for high-volume production of identical parts.
✅ Rigid & Stable Construction
High-rigidity cast iron bed and reinforced frame ensure zero deflection during continuous high-speed cutting, ensuring consistent accuracy across both spindles.
✅ Automatic Tool Change Option
Dual 24-position tool magazines enable fast tool changes for each spindle, supporting multi-process machining without manual intervention.
✅ Industry-Optimized Design
Specially designed for high-volume new energy vehicle and rail transit applications, perfect for producing structural profiles and battery tray components at scale.
✅ Global Export Ready
Fully CE-certified with customizable voltage configurations and complete export documentation, ready for international shipping.
